T-시리즈

현장 맞춤형 모듈식 파이프 커팅기.
제조현장에 맞게 다양한 선택사양을 제공합니다.

문의하기

Model	Max. Material Length For Loading	Max. Material Length For Unloading	Square	Round	C-shaped	L-shaped	H-beam	I-beam	Three Chucks	Bevel-cut
T16D-Pro	6200mm/9200mm	2000mm/2500mm/3000mm/4000mm	160mm	160mm	100mm	100mm	100mm	100mm	☑	☑
T22D-Pro	6200mm/9200mm/12000mm	2000mm/2500mm/3000mm/4000mm	230mm	230mm	140mm	110mm	140mm	140mm	☑	☑
T25D	6200mm/9200mm	2000mm/2500mm/3000mm/4000mm	200mm	250mm	200mm	150mm	150mm	200mm	☑	☑
T28D	6200mm/9200mm/12000mm	2500mm/4000mm	280mm	280mm	220mm	180mm	200mm	220mm	☑	☑
T33D	6200mm/9200mm/12000mm	2000mm/2500mm/3000mm/4000mm	230mm	330mm	220mm	180mm	200mm	220mm	☑	☑
T35D	6200mm/9200mm/12000mm	4000mm	250mm	350mm	250mm	200mm	200mm	250mm	☑	☑
T36D-Pro	6200mm/9200mm/12000mm	2500mm/4000mm	360mm	360mm	300mm	200mm	250mm	250mm	☒	☑

Modular Optionals (모듈 선택사양)
